Korg MS-20 Mini

The original analog circuitry

The MS-20 mini painstakingly replicates the original MS-20. A development team led by the original engineers themselves worked to recreate the original circuitry, and when it was necessary to substitute a part, these engineers made the decisions based on careful listening, in order to reproduce the original sound faithfully.
In fact, the sound of the MS-20 mini has a somewhat bright and extreme quality to it because its sound is that of an original MS-20 in mint condition at the time it went on sale, before any of the components aged.

2VCO / 2VCF / 2VCA / 2EG / 1LFO structure

The MS-20 mini reproduces the distinctive synthesis of the MS-20; two oscillators with ring modulation, and envelope generators with hold and delay. The VCA maintains the basic design of the original, but it’s been modified to produce less noise than the original.
Self-oscillating high-pass/low-pass filters with distinctive distortion
One of the greatest characteristics of the MS-20 was its powerful filters, which provided resonance on both the high-pass and the low-pass. Maximizing the resonance would cause the filter to self-oscillate like an oscillator, producing a distinctive and dramatic tonal change that was acclaimed as inimitable, and was later used on the monotron and monotribe.
The filter circuit was changed mid-way through the production lifecycle of the MS-20; the MS-20 mini uses the earlier filter, which was felt to be superior due to its more radical sound.

Korg MS-20 Mini Monophonic Analog Synthesizer Features:

• The legendary 1978 Korg MS-20 analog synthesizer reborn
• Built to 86% scale, making this MS-20 more portable than ever
• Provides powerful vintage sound, from deep, growling basses to crisp, rounded leads
• Two oscillators with ring modulation provide a wide range of sound
• Envelope generators with delay and hold add exciting motion to your tone
• VCA (Voltage Controlled Amp) maintains the original basic design, but with reduced noise
• First-generation filter design (highpass/lowpass with peak/resonance) capable of self-oscillation
• ESP (External Signal Processor) utilizes the pitch or volume of an external audio source to control the synthesizer
• 1/8\" jack-based patching bay lets you create complex sounds
• 37-note keyboard is also 86% the size of the original
• MIDI In and USB connector provides keyboard and DAW MIDI connectivity
• Includes original MS-20 owner\'s manual and settings chart
